Failures happen: the key is shortening time-to-understanding. In this guide, you’ll automate triage when a GitHub Actions workflow fails: pull logs and artifacts, get an AI summary from GitHub Models, open an issue with concrete next steps, and optionally assign it to the Copilot coding agent.
What you’ll build
Trigger on failed workflow runs you care about
Collect logs and artifacts for context
Call GitHub Models for a concise summary and probable fix
File a GitHub issue with reproduction hints and links
Optionally assign the issue to the Copilot coding agent
Prerequisites
GitHub Actions enabled in your repo
GitHub Models access and a token for inference:
If you’re using a fine-grained PAT: add models:read scope
Or use secrets.GITHUB_TOKEN in public repos where Models are enabled for the org
Optional: Copilot coding agent enabled at the org or user level to assign issues to
Workflow: AI-assisted failure triage
Below is a complete workflow you can drop into .github/workflows/ai-triage.yml. It triggers when selected workflows complete and only proceeds if they failed.
name: AI triage failed runson:
workflow_run:
workflows: ["*"]
types: [completed]permissions:
actions: readcontents: readissues: writechecks: writemodels: readjobs:
triage:
if: ${{ github.event.workflow_run.conclusion == 'failure' }}runs-on: ubuntu-latestenv:
PAT_WITH_ISSUES_WRITE: ${{ secrets.PAT_WITH_ISSUES_WRITE }}steps:
- name: Set variablesid: varsshell: bashrun: | echo "run_id=${{ github.event.workflow_run.id }}" >> "$GITHUB_OUTPUT"
echo "run_url=${{ github.event.workflow_run.html_url }}" >> "$GITHUB_OUTPUT"
echo "repo=${{ github.repository }}" >> "$GITHUB_OUTPUT"
echo "branch=${{ github.event.workflow_run.head_branch }}" >> "$GITHUB_OUTPUT"
echo "sha=${{ github.event.workflow_run.head_sha }}" >> "$GITHUB_OUTPUT" - name: Download workflow logs (zip)shell: bashenv:
GITHUB_TOKEN: ${{ secrets.GITHUB_TOKEN }}run: | set -euo pipefail
mkdir -p logs
# Follow redirect to the actual ZIP download URL
curl -sSL -H "Authorization: Bearer $GITHUB_TOKEN" \
"https://api.github.com/repos/${{ steps.vars.outputs.repo }}/actions/runs/${{ steps.vars.outputs.run_id }}/logs" \
-o logs/run-logs.zip || true
unzip -q logs/run-logs.zip -d logs || echo "No logs found." - name: Download test-results artifactuses: dawidd6/action-download-artifact@v11with:
github_token: ${{ secrets.GITHUB_TOKEN }}run_id: ${{ steps.vars.outputs.run_id }}repo: ${{ steps.vars.outputs.repo }}name: test-resultspath: artifacts/test-resultsif_no_artifact_found: ignore - name: Summarize TRX test results (check run + outputs)id: reportif: always()uses: dorny/test-reporter@v2with:
name: TestSummaryartifact: test-resultspath: "**/*.trx"reporter: dotnet-trxonly-summary: trueuse-actions-summary: truefail-on-error: falsefail-on-empty: false - name: Build AI prompt (TRX summary, artifacts, logs)shell: bashrun: | {
echo "Failure in ${{ steps.vars.outputs.repo }} on branch ${{ steps.vars.outputs.branch }} at ${{ steps.vars.outputs.sha }}"
echo "Run: ${{ steps.vars.outputs.run_url }}"
echo
echo "Goal: Summarize failure cause and propose next steps. Be concise and actionable."
echo
echo "=== Test summary (TRX via test-reporter) ==="
echo "- Passed: ${{ steps.report.outputs.passed || '0' }}"
echo "- Failed: ${{ steps.report.outputs.failed || '0' }}"
echo "- Skipped: ${{ steps.report.outputs.skipped || '0' }}"
if [ -n "${{ steps.report.outputs.url_html }}" ]; then
echo "- Report: ${{ steps.report.outputs.url_html }}"
fi
echo
echo "=== Artifacts ==="
find artifacts -type f -maxdepth 3 | sed 's/^/- /' || true
echo
echo "=== Logs (head) ==="
find logs -type f -name '*.txt' | head -n 3 | xargs -r -I{} sh -c 'echo "--- {} ---"; head -n 60 "{}"'
echo
echo "=== Logs (tail) ==="
find logs -type f -name '*.txt' | head -n 3 | xargs -r -I{} sh -c 'echo "--- {} ---"; tail -n 60 "{}"'
} > prompt.txt - name: AI triage summaryid: aiuses: actions/ai-inference@v1with:
model: openai/gpt-4osystem-prompt: You are a senior CI engineer. Be concise.prompt-file: ./prompt.txt - name: Ensure labels existuses: actions/github-script@v7with:
script: | const owner = context.repo.owner;
const repo = context.repo.repo;
const labels = [
{ name: 'ci-failure', color: 'B60205', description: 'CI pipeline failure' },
{ name: 'needs-triage', color: 'D4C5F9', description: 'Requires triage' },
];
for (const l of labels) {
try {
await github.rest.issues.getLabel({ owner, repo, name: l.name });
} catch {
await github.rest.issues.createLabel({ owner, repo, name: l.name, color: l.color, description: l.description });
}
} - name: Create issueid: issueuses: actions/github-script@v7env:
BRANCH: ${{ steps.vars.outputs.branch }}RUN_URL: ${{ steps.vars.outputs.run_url }}SHA: ${{ steps.vars.outputs.sha }}AI: ${{ steps.ai.outputs.response }}with:
script: | const owner = context.repo.owner;
const repo = context.repo.repo;
const title = `CI failure: ${(context.payload.workflow_run?.name ?? 'CI')} on ${process.env.BRANCH}`;
const ai = process.env.AI || '';
const summary = ai.trim() ? ai : 'No AI summary produced';
const body = `### AI summary\n\n${summary}\n\n---\n\nRun: ${process.env.RUN_URL}\nCommit: ${process.env.SHA}`;
const res = await github.rest.issues.create({ owner, repo, title, body, labels: ['ci-failure','needs-triage'] });
core.setOutput('number', res.data.number.toString());# Optional: assign to Copilot coding agent with a user PAT that can assign issues - name: Assign to Copilot coding agent (optional)if: ${{ env.PAT_WITH_ISSUES_WRITE != '' }}uses: actions/github-script@v7env:
USER_PAT: ${{ secrets.PAT_WITH_ISSUES_WRITE }}ISSUE_NUMBER: ${{ steps.issue.outputs.number }}with:
github-token: ${{ env.USER_PAT }}script: | const owner = context.repo.owner;
const repo = context.repo.repo;
const issue_number = Number(process.env.ISSUE_NUMBER);
// GraphQL to get suggested actors
const actorsRes = await github.graphql(
`query($owner:String!,$name:String!){
repository(owner:$owner, name:$name) {
suggestedActors(capabilities:[CAN_BE_ASSIGNED], first:100) {
nodes { login __typename ... on Bot { id } ... on User { id } }
}
}
}`,
{ owner, name: repo }
);
const candidates = ['copilot-swe-agent','copilot-agent','copilot'];
const nodes = actorsRes?.repository?.suggestedActors?.nodes || [];
const match = nodes.find(n => candidates.includes(n.login));
if (!match) {
core.info('Copilot agent not suggested. Skipping assignment.');
return;
}
// Get issue node id
const issueRes = await github.graphql(
`query($owner:String!,$name:String!,$num:Int!){ repository(owner:$owner, name:$name) { issue(number:$num) { id } } }`,
{ owner, name: repo, num: issue_number }
);
const issueId = issueRes?.repository?.issue?.id;
if (!issueId) { core.warning('Issue ID not found'); return; }
// Assign via GraphQL
await github.graphql(
`mutation($id:ID!,$actor:ID!){
replaceActorsForAssignable(input:{assignableId:$id, actorIds:[$actor]}) {
assignable { __typename }
}
}`,
{ id: issueId, actor: match.id }
);
Notes:
API host: models.github.ai supports org-scoped calls at /orgs/{org}/inference/chat/completions if you need attribution.
Headers: include Authorization: Bearer <token>, Accept: application/json, Content-Type: application/json, and X-GitHub-Api-Version.
Model IDs are publisher/name (e.g., openai/gpt-4.1). Switch models freely in the body.
Logs endpoint returns a 302 to a temporary zip URL; using curl -L or -sSL follows it.
gh run download extracts artifacts by name into subfolders. Use --name to filter if needed.
Troubleshooting
401/403 from Models: ensure your token has access to GitHub Models. For fine-grained PATs, add models:read.
Empty AI response: check .choices[0].message.content; if null, inspect response.json for errors.
Copilot coding agent assignment fails: verify your plan (Pro+ or Enterprise) and that the agent is enabled for the repo.
Logs too large: adjust head/tail counts or filter to failing job logs only.
Next steps
Enrich the prompt with structured test failures: parse TRX or JUnit XML and include a concise table of failing tests.
Attach summary.md, the prompt, and key logs as issue attachments or comments.
Enable the Copilot coding agent for your repo and flip the assignment step to true to let Copilot propose a fix.
